Product Description
Superflex - Extra Flexible Tri-rated Cable
Application
Extra-Flex is a super flexible Tri-rated cable with a Class 6 conductor.
Usually selected in place of class 5 Tri-rated cable in situations where space is at a premium. This cable is often used in confined spaces where a reduced bend radius is required.
It has a flame retardant PVC insulation and can be used in high working temperatures up to 105℃
Standards
To CSA Type TEW, UL Type AWM Style 1015 (including UL1028, UL1283 and UL1284) and manufactured to BS6231.
Construction
Plain annealed Class 6 Copper conductor
PVC Insulation
Temperature Rating:
105℃
Voltage Rating:
600/1000V (Uo/U)
| Nominal Cross Sectional Area of Conductor |
Nominal No. & Diameter of Wires |
Radial Thickness of Insulation |
Nominal Overall Diameter |
Maximum AMPS |
Weight kg/km |
| 10mm2 |
315/0.2mm |
1.2mm |
6.8mm |
75 |
128 |
