£255.00
For use in the supply of energy for portable or mobile equipment and heavy-duty and construction-level wiring, our H07RN-F cable is an excellent choice. Created for power supply, our H07RN-F cable is often used in intense environments, protecting the copper within its rubber sheath from excessive heat, pressure, and chemical degradation. Our H07RN-F cable is not only robust but also extremely flexible. The PCP neoprene outer sheath is oil and flame retardant. Its flexibility means it can be used in all manner of spaces and all kinds of purposes including worksites, construction yards, docks, garages, building sites, stage and audio visual, drainage and water treatment, and severe industrial environments.
Inner Conductor | Stranding | Insulation | Outer Sheath | Diameter mm | Min bending radius indoor/outdoor mm | Cable Weight | Operating Temp | Typical Applications |
---|---|---|---|---|---|---|---|---|
Cu | Class 5 Flexible Stranded Copper | EPR (Ethylene Propylene Rubber) | Black neoprene (PCP) outer sheath to BS7919:2001 | 14mm | 6 x Ø for cables not exceeding 25mm Static: 8 x Ø for cables exceeding 25mm Flexing: 15 x Ø | 381kg/km | -25°C to +85°C | Portable saws, grinders, welders, pumps, transformers, as temporary lighting cable and feed cable to heavy mobile equipment. Distribution cables from mobile generators. |
Type: H07RN-F 1c-25mm2
